Unique
shape, another excellent option for high-performance mountain bikes; classic
forged aluminum crown + magnesium alloy lower leg, diameter 34mm, high-strength
and lightweight aviation-grade aluminum stanchion; newly upgraded air
suspension system, bearing-type sliding sleeve, Further improve the smoothness
of the stanchion; optional functions are complete, easy to maintain, and adapt
to various complex road conditions.
| MODEL: | A-TNL | A-TNL-R | A-RL | A-RL-R | |||
|---|---|---|---|---|---|---|---|
| STEERER | Aluminum 7075/Steel Ø30(39.8)*28.6 | ||||||
| CROWN PITCH | P130mm | ||||||
| CROWN | Aluminum | ||||||
| STANCHION | Aluminium- Ø34mm hard Anodize | ||||||
| CASTING | Magnesium open dropout100*Ø9.8mm | ||||||
| SPRING | Air | ||||||
| WHEEL SIZE | 27.5" 29" | ||||||
| TRAVEL | 120mm | ||||||
| BRAKE TYPE | Disc Brake | ||||||
- A: Air
- R: Rebound
- RL: Remote Lock-out
- TNL: Hydraulic Lock-out
